Medical Equipment's
Manual Wheel Chair KY951AC-56
Manual Wheel Chair KY951AC-56
Manual Wheel Chair KY951AC-56 from Kaiyang Medical is a manual wheelchair built for those who demand both exceptional strength and sophisticated comfort. Imagine navigating bustling city streets or embarking on nature trails with unwavering confidence, all thanks to this meticulously crafted machine. KEY FEATURES:- Properties Rehabilitation Therapy Supplies
- Brand Name kaiyang
- Model Number KY951AC-56
- Type Wheelchair
- Color Black
- Heavy Duty Wheelchair with Foldable Backrest
Infusion Pump St-1000 Samtronic
Brand: Samtronic, Brazil
Model: ST-1000
please click here to download the full catalog infusionpump samtronic.pdf
Touch Screen Patient Monitor MD9015
Touch Screen Patient Monitor MD9015
Touch Screen Patient Monitor MD9015 is a touch screen 15 inch patient monitor by Meditech 192-hour trend graph,1000 group of blood pressure list,ST segment measurements, arrhythmia analysis and more functions, Support up to 32 TCP/IP network connection,composed of a central information system.. Comes with remote control. Please see our complete range of Patient Monitor & Multiparameter Monitors Features:- 5” high resolution color TFT display with maximum 13 waveforms
- Full touch-screen enables intuitive operation by clicking on the specific parameters of the waveform in real time, standard configuration includes the navigation knob
- Pacemaker detection, electrosurgical interference proof
- Defibrillation protection and defibrillation synchronization
- SD Card slot enable memory extension for large data storage
- USB and serial port enable abundant future upgrades
- VGA output and Analog output
- OxyCRG available to judge the respiration and circulation function for neonate
- Large font display
- Arrhythmia and S-T segment analysis
- Built-in rechargeable Li-ion (6hours maximum with 2x 4200mAh batteries)
- Nurse Call function and bi-directional communication with MFM-CMS central station
- Multi language: English/Simplified Chinese/Traditional
- Chinese/Spanish/Czech/Italian/Polish/French/German/Brazilian/Portugese/Russian.
- Standard configuration: 3/5-lead ECG, NIBP, SpO2, RESP, 2-Temp, PR
- Optional: 12-lead ECG, Nellcor-SpO2, Omron NIBP, 2-IBP/4-IBP, Mainstream/Side stream CO2,
- CO, Multi-Gas, Full Touch Screen, Thermal Recorder, WLAN Accessory
- Large Data Storage: 120 hours graphic and tabular trends of all parameters; 1200 sets of NIBP
- measurement and 70 alarm events; 2-USB ports and SC card slot ensure data storage/function upgrades.
- Clinical data can be viewed and managed via Patientcare viewer software (To be released)
- Clinical network: bi-directional communication with CMS-2000 central station by wired or wireless connection,
- Complete and flexible mounting solution for ICU and operation room. High-end parameters for more flexible clinical applications.
- Invasive Blood Pressure (IBP)
- Carbon dioxide (CO2) Module
- Masimo SpO2 Module
- Thermal Printer
Touch Screen Patient Monitor MD9015
Specification: Electrocardiogram (ECG)- Input mode Five-lead ECG input / three-lead ECG input
- Lead selection I, II, III, aVR, aVL, aVF, V-
- Gain selection AUTO,0.25X,0.5X,1X,2X,4X
- Operating mode Diagnostic mode, monitoring mode, operation mode
- Calibration signal 1mV ±5%
- Protection The isolation voltage 4000V, 50/60Hz. Anti-high-frequency interference of electric knife.
- Anti-defibrillation protection.
- Pacemaker at the same time use Support
- Electrode off instructions Each electrode (RL excluded)
- Scanning speed 12.5mm/s, 25 mm/s, 50 mm/s
- Common mode rejection ratio ≥90dB
- Input impedance ≥5.0MΩ
- Measuring range Adult 30 ~ 300bpm, newborns 30 to 350 bpm
- Resolution 1 bpm
- Accuracy < ±5bpm
- Heart rate sensitivity ≥0.20mVp-p
- Alarm range 15 to 350 bpm, upper and lower limits
- Alarm indication Audible and visual alarm, display the data and parameters flashing display alarm message text prompts, there are three levels of alarm
- SPO2 Range: 1% to 99%
- Resolution: 1%
- Accuracy: 70% to 99% range: ±2%;
- 1% to 69% range: ±5%;
- Method: Dual wavelength LED
- ST-segment measurement range -2.0～+2.0mV
- ST-segment measurement accuracy Within the range of -0.8 ~ +0.8 mV: ± 0.02mV or reading± 10%, Whichever is greater; Other range: undefined
- Resolution 0.01mV
- ST-segment update cycle 10s
- ST segment alarm range -2.0 ~ +2.0 MV, the upper and lower limits continuously adjustable
- Arrhythmia types 13 kinds of (scalable)
- Respiration Rate
- Rate: 2 to 120 bpm (CO2)
- Technique: Oscillometric during inflation
- Range: Adult/Pediatric: 40 to 240 mmHg
- Neonate: 10 to 150 mmHg
- Measurement Cycle: < 40 sec. typical
- Cycles (Selectable): 2, 3, 5, 10, 15, 30 min; 1, 2, 4 hr
- STAT Mode: 5 minutes of continuous readings
- Max. Allowable Cuff
- Pressure: Adult: 300mmHg
- Pediatric: 240 mmHg;
- Neonate: 150 mmHg
- Resolution: 1 mmHg
- Transducer Accuracy: ±2 mmHg or ±2% of reading,
- Heart (Pulse) Rate
- Range: 30 to 250 bpm
- Accuracy: ±2 bpm or ±3%, whichever is greater
- Interface form External interface Range of
- measurement 0~10 kPa or (0~75) mmHg
- precision（error） (0kPa~5.4kPa) the error is ±0.3kPa、
- (5.5kPa~10.0kPa)the error is ±0.7kPa
- Alarm upper limit 2.1~13.2 kPa
- Alarm lower limit 0~6.5 kPa
- time 12s
- EtCO2 exist
- Unit kPa / mmHg / %
- Compatibility
- external main stream and side stream are compatible
Vibration Meter – Lutron – Model: VB-8200
Vibration Meter - Lutron - Model: VB-8200
Vibration meter - Lutron - Model: VB-8200 is made by Lutron, Taiwan. Applications for industrial vibration monitoring All industrial machinery vibrates. The level of vibration is a useful guide to machine condition. Poor balance, misalignment and looseness of the structure will cause the vibration level increase, it is a sure sign that the maintenance is needed. Click the link to download product catalog VB-8200.pdf The Features of this product is as follow: - Features: -- Frequency range 10 Hz - 1 kHz,
- sensitivity relative meet ISO 2954.
- Supply with vibration sensor & magnetic base, full set.
- Velocity range : 200 mm/s.
- Acceleration range : 200 m/s^2
- RMS & Peak measurement.
- Data hold, Memory ( Max. & Min. ).
- Separate vibration probe.
- RS 232 computer interface.
- Optional data acquisition software.
- Microcomputer circuit.
- Auto shut off saves battery life.
- Hard carrying case include.
- Frequency range 10 Hz - 1 kHz, sensitivity relative meet ISO 2954.
- Professional vibration meter supply with vibration sensor & magnetic base, full set.
- Velocity measuring range 200 mm/s.
- Acceleration measuring range 200 m/s^2.
- RMS & Peak measurement.
- Data hold button to freeze the desired reading.
- Memory function to record maximum and minimum reading with recall.
- Separate vibration probe, easy operation
- RS 232 computer interface.
- Optional data acquisition software for data record & datalogger.
- Super large LCD display.
- Microcomputer circuit, high performance.
- Auto shut off saves battery life.
- Built-in low battery indicator.
- Heavy duty & compact housing case.
- Complete set with the hard carrying case.
Oxygen Concentrator Dual Flow JAY-5
Oxygen Concentrator Dual Flow JAY-5
Oxygen Concentrator Dual Flow JAY-5 with nebulizer is an electronic equipment which is influenced by Radio Frequency Interference (RFI). When there is strong electromagnetic interference, maybe the LCD will be slightly affected, but the Oxygen Concentrator Dual Flow Jay-5 is still running. ALWAYS exercise CAUTION with regard to the use of portable communications equipment in the area around such equipment. JAY Series oxygen concentrator is a device that extracts oxygen from atmospheric air. It will typically be an electrically powered molecular sieve (artificial zeolite) used to separate nitrogen from ambient air. It could be applied widely in the hospitals at all different level, clinics, health centers and family nursing, health care for the old person, mental workers and students, etc.. The oxygen concentrator can supply 1-2 patients simultaneously, with steady oxygen flowing out, safe and reliable, low cost, adjustable flow. The key parts of the concentrator adopt anti-tiring and anti-aging design, and the planned life of the whole concentrator reaches up to 20,000 hours or 5 years, whichever comes first. Click to download the user manual of Longfian_Oxygen Concentrator Dual Flow Jay-5.pdf TECHNICAL SPECIFICATION
Operation conditions and Environment
- Ambient temperature: 10 -40℃
- Relative humidity: 30%-85%
- Air pressure: 700 hPa-1060 hPa
- Altitude: Up to 2286m without degradation; Consult your equipment provider for further
- information regarding to 2286m to 4000m
- No corrosive gas and strong magnetic field around.
Portable Ultrasound Machine S4i Meditech
Portable Ultrasound Machine S4i Meditech
Portable Ultrasound Machine S4i Meditech adopts advanced high-precision digital beam former, continuous dynamic focusing, dynamic aperture and dynamic, apodization changes, making the image real, rich in detail. It has powerful standard PC platform, professional design and easy operation of the control panel which meets the increasing requirements of the clinical diagnosis. Availability of Data recording and transfer software. It is also to to noticed that S4i Ultrasound machine is CE Certified. For more information about Portable Ultrasound Machine S4i Meditech or quotations, rates, questions and queries please feel free to contact us at +92-322-4602203 or Email: zirarenterprises@gmail.com, info@zirarenterprises.comFeatures:
- Full digital imaging technology
- Crystal-clear Image
- Computer platforms, Abundant functions
- Powerful image and report management
- 10 inch no interlaced CRT monitor
- Silica gel backlight keyboard
- DICOM display and transfer
- Pretty, portable and light
- Large volume Storage and cine loop
- 128/256/512/1024 frame cine loop
- Broadband Multi frequency probes
- 8 segment TGC, 16 step zoom
- Complete application software packages
- 2 probe connector
- Compatible with USB laser/inkjet printers
- 3D Image Function(optional)
- THI
- Imaging technologies
- Intelligent Speckle Reduction
- 3D reconstruction
- Abundant user management functions
- One key recording
- User defined OB table
- Expert vocabulary and report templates
Specification:
- Displaying mode: B mode, B/B mode, B/M mode, M mode, 4B mode
- Scanning mode: Electric convex, Electric linear, Electric micro-convex
- Displaying depth: 20mm-310mm
- Probe port: 1 OR 2
- Voltage: AC100V-240V
- Output port: USB,DICOM,VGA,
- Gray scale: 256
- Time gain: Gain：10～255dB adjustable ;time gain compensation(TGC): 8 segments, which can be adjusted independently in B mode and M mode.
- Storage function: image storage, cine loop storage, mass storage capacity≥10G.measurement result storage, report storage
- Cine-loop: 64,128,256,512,1024 frames can be chosen；auto/manual cine loop
- Patient information: Hospital name; patient name; case number； patient age； gender；
- Focusing mode: 1-4 selectable focus , multiple combination way, focus position moving available
- Real-time zoom, local zoom: Multi-stage display rate(depth ascension)function, roll line function
- Annotation function: Annotation at the image area
- Body mark: 140
- Cursor: The combination of Trackball and keyboard
- Color display: 43 color display function
- DC-AC: AC/DC
- Report: Display, storage and print report directly.
- Variable angle scanning: 16kinds of angle scanning include:25%,30%,35%,…100
- Image processing: Pre-processing, post-processing, dynamic range, frame correlation, line correlation, edge enhancement, black/white conversion, left/right conversion, up/down conversion, contrast, brightness, gamma correction
- Dynamic range: Continuously adjustable： 20~150dB
- Measurement and calculation: B mode: distance, circumstance, area, volume, angle, histogram, hip joint angle
- M mode: heart rate, time, slope
- Abdomen: uterus, cervix, endometrial, ovary, ovarian follicle, cyst, enclosed mass
- Obstetric: 14（AC,BPD,CRL,FL,THD,GS,OFD,HUMERUS,TIDIA,ULNA,HC,TAD,APTD,FTA）measure gestation age,
- fetal weight, AFI
- Cardiology: LV.LV function, LVPW,RVAWT, aorta, mistral valve
- Urology: L/R kidney volume, bladder volume, prostate volume
- Small organs: Ophthalmology. Thyroid, residual urine volume
Suction Machine Shinova 940-D
Brand: Shinova, China
Model: 940-D
please click the link to download catalog Suction-Machine 940-D.pdf
